The axial calibration presses of the KA product line from Frey are designed for the reworking of sintered parts. They complement our powder presses and are integrated into your production process by handling.
The repressing of the parts increases the manufacturing quality and compensates for inaccuracies that may arise, for example, due to material shrinkage.
Individual upstream and downstream process steps – for example, aligning the compacts, wetting with calibration oil, faceting or thread cutting – can be realized on request!
Press force upper piston 500kN
Stroke upper piston 200mm
Force lower piston 200kN trigger/
filling height 100mm
Press force upper piston 1200kN
Stroke upper piston 300mm
Ejection force lower piston 480kN
Trigger 120mm
Press force upper piston 2000kN
Stroke upper piston 350mm
Ejection force lower piston 800kN
Trigger 150mm
Press force upper piston 3500kN
stroke upper piston 350mm
force lower piston 2000kN
filling height from 150mm
Press force upper piston 5000kN
stroke upper piston 350mm
force lower piston 2000kN
Filling height from 150mm
Pressing force upper piston 6500kN
Stroke upper piston 350mm
Pressing force lower piston 2600kN trigger
Filling level from 150mm
HE – High Efficiency servo pump
S – Proven hydraulics with control valve technology
